Philosophy: ABAQUS as a Warning Example

Our Position

ABAQUS element design is a cautionary tale in software engineering.

From a computer science perspective, ABAQUS demonstrates what happens when you violate separation of concerns and mix orthogonal dimensions into a single type hierarchy. We're software engineers, and we recognize bad design when we see it - even in commercial products.

We don't dance to ABAQUS's whistle. We support their format (interoperability) but don't replicate their architectural mistakes (exponential hell).

The Problem: Exponential Complexity

ABAQUS creates separate element types for every combination of:

• Topology (3 nodes, 4 nodes, 8 nodes...)
• Physics (plane stress, plane strain, axisymmetric, 3D...)
• Integration (full, reduced, selective...)
• Features (hybrid, incompatible modes, temperature...)

Example: The Triangle Family

CPS3  = 3 nodes + Plane Stress + Standard
CPE3  = 3 nodes + Plane Strain + Standard
CAX3  = 3 nodes + Axisymmetric + Standard
C3D3  = 3 nodes + 3D + Standard
...

Same 3-node triangle topology, different physics. But ABAQUS treats them as completely different element types.

Result: 100+ element types with massive code duplication.

The Growth Pattern

Types = Topologies × Physics × Integration × Features

Example:
  10 topologies × 4 physics × 3 integration × 2 features = 240 types

Adding one topology → Create 24 new variants (4×3×2)
Adding one physics → Create 60 new variants (10×3×2)

This is O(exponential) complexity. Unmaintainable. Unextensible.

Why This Is Wrong: SOLID Principles Violated

ABAQUS's element design is a textbook example of violating every SOLID principle from object-oriented design. Let's examine each violation:

S - Single Responsibility Principle ❌

Principle: "A class should have one, and only one, reason to change."

ABAQUS Violation: Each element type has multiple responsibilities:

• Topology (geometric shape and connectivity)
• Physics formulation (stress state, material behavior)
• Integration scheme (quadrature rules)
• Special features (hybrid, incompatible modes)

! CPS3 is responsible for ALL of these:
SUBROUTINE CPS3_STIFFNESS(...)
  ! Topology: 3-node triangle shape functions
  ! Physics: Plane stress constitutive equations
  ! Integration: Gauss quadrature
  ! Assembly: Element stiffness contribution
END

Consequence: Change anything → must modify the entire element type. Want reduced integration? Create CPS3R. Want hybrid formulation? Create CPS3H. Exponential explosion.

O - Open/Closed Principle ❌

Principle: "Software should be open for extension, closed for modification."

ABAQUS Violation: Cannot add new physics without modifying the codebase:

Want new physics formulation?
1. Create N new element types (one per topology)
2. Modify element registry
3. Duplicate shape functions and integration
4. Update documentation, tests, manuals

Modern approach (extension without modification):

# Add new physics - zero modifications to existing code
struct HyperelasticFormulation end

function stiffness(elem::Tri3, phys::HyperelasticFormulation, integ::FullIntegration)
    # New behavior via multiple dispatch
    # Tri3 code unchanged
end

L - Liskov Substitution Principle ❌

Principle: "Derived classes must be substitutable for their base classes."

ABAQUS Violation: Cannot substitute CPS3 for CPE3 even though they're the same topology:

! These SHOULD be interchangeable (same topology)
! But they're not - different physics hardcoded
CALL ELEMENT_STIFFNESS(elem_type='CPS3', ...)  ! Plane stress
CALL ELEMENT_STIFFNESS(elem_type='CPE3', ...)  ! Plane strain

! Cannot substitute! Different hardcoded behavior

Modern approach (proper substitution):

# Same topology, different physics - fully substitutable
function solve(topology::Triangle3Node, physics::PhysicsModel)
    # Topology is substitutable, physics is parameter
end

solve(Tri3([1,2,3]), PlaneStress())   # ✓ Works
solve(Tri3([1,2,3]), PlaneStrain())   # ✓ Same topology, different physics

I - Interface Segregation Principle ❌

Principle: "Clients shouldn't depend on interfaces they don't use."

ABAQUS Violation: Element types expose everything even when only topology is needed:

! Just need connectivity for visualization
CALL GET_ELEMENT_NODES(elem_type='C3D20', ...)

! But C3D20 includes:
! - 20-node hexahedron topology          (NEEDED)
! - 3D stress formulation                (NOT NEEDED)
! - Quadratic shape functions            (NOT NEEDED)
! - Integration point data               (NOT NEEDED)
! - Material interface                   (NOT NEEDED)

! Fat interface - 80% irrelevant for this use case

Modern approach (segregated interfaces):

# Topology interface (what AbaqusReader provides)
topology = Hex20([1,2,3,...,20])  # Just connectivity
nodes = get_nodes(topology)        # Simple, focused interface

# Physics interface (user adds if needed)
physics = ThreeDimensionalStress()
stiffness = compute(topology, physics)  # Separate concerns

D - Dependency Inversion Principle ❌

Principle: "Depend on abstractions, not concretions."

ABAQUS Violation: Everything depends on concrete element type names:

! Tight coupling to concrete types
IF (elem_type == 'CPS3') THEN
  CALL CPS3_ROUTINE(...)
ELSEIF (elem_type == 'CPE3') THEN
  CALL CPE3_ROUTINE(...)
ELSEIF (elem_type == 'CAX3') THEN
  CALL CAX3_ROUTINE(...)
! ... 240+ more cases
ENDIF

! Cannot abstract! Concrete type names everywhere

Modern approach (depend on abstractions):

# Abstract interfaces
abstract type Element end
abstract type Physics end

# Concrete implementations
struct Tri3 <: Element end
struct PlaneStress <: Physics end

# Depend on abstraction, not concretions
function stiffness(elem::Element, phys::Physics)
    # Works with ANY element and physics type
    # Multiple dispatch resolves concrete behavior
end

SOLID Violations Summary

Result: Unmaintainable, unextensible, O(exponential) complexity.

Additional Design Violations

Violates Separation of Concerns

Topology and physics are orthogonal - they vary independently, but ABAQUS couples them.

Violates DRY (Don't Repeat Yourself)

! Same shape functions duplicated across physics variants
SUBROUTINE CPS3_STIFFNESS(...)
  ! Shape functions for 3-node triangle
END

SUBROUTINE CPE3_STIFFNESS(...)
  ! Shape functions for 3-node triangle  (DUPLICATED!)
END

SUBROUTINE CAX3_STIFFNESS(...)
  ! Shape functions for 3-node triangle  (DUPLICATED!)
END

Not Composable

Modern software composes behavior:

stiffness = topology ∘ physics ∘ integration

ABAQUS has monolithic types instead. No composition, no reuse.

The Modern Solution: Separation via Type Systems

What We Should Do (Julia Multiple Dispatch)

# Define concerns independently
struct Tri3
    nodes::Vector{Int}  # Topology only - geometry
end

struct Quad4
    nodes::Vector{Int}
end

# Physics formulations - separate types
struct PlaneStress end
struct PlaneStrain end
struct Axisymmetric end

# Integration schemes - separate types
struct FullIntegration end
struct ReducedIntegration end

# Compose via multiple dispatch
function stiffness(elem::Tri3, phys::PlaneStress, integ::FullIntegration)
    # Only this specific combination
end

function stiffness(elem::Tri3, phys::PlaneStrain, integ::FullIntegration)
    # Different physics, same topology - reuses Tri3 shape functions
end

# Extensibility: Add new physics without touching topology
struct NonlinearElastic end

function stiffness(elem::Tri3, phys::NonlinearElastic, integ::FullIntegration)
    # New physics, existing topology - zero modifications to Tri3 code
end

Complexity: O(T + P + I) types instead of O(T × P × I)

Result: 19 types instead of 240

C++ Templates

// Topology
template<int N>
class Triangle {
    std::array<int, N> nodes;
};

// Compose at compile time
template<typename Physics, typename Integration>
Matrix stiffness(Triangle<3>& elem, Physics p, Integration i) {
    // Specialized per combination
    // Zero runtime overhead
}

// Extensibility: Add new physics
struct NewPhysics { };

// Automatically works with all topologies!

Rust Traits

// Separate traits for each concern
trait Element {
    fn nodes(&self) -> &[usize];
}

trait Formulation {
    fn stress_state(&self) -> StressState;
}

trait Quadrature {
    fn points(&self) -> Vec<Point>;
}

// Compose orthogonally
fn solve<E: Element, F: Formulation, Q: Quadrature>(
    elem: &E, form: &F, quad: &Q
) {
    // Type system ensures valid combinations
}

Why ABAQUS Is This Way: Historical Context

1970s FORTRAN Legacy

ABAQUS originated in the 1970s when:

• FORTRAN was the dominant language
• Procedural programming was the only paradigm
• Subroutines were the abstraction mechanism
• Templates, traits, and multiple dispatch didn't exist

Design consequence: Each element type = one subroutine. Different behavior = different subroutine.

Technical Debt Accumulation

After 40+ years:

• Cannot break existing input files (millions of them exist)
• Backward compatibility is absolute requirement
• Refactoring is commercially impossible
• "Add feature" → "add element type" became the pattern

Result: Architecture frozen in 1970s paradigm despite modern alternatives.

Why Dassault Didn't Fix It

1. Legacy inertia - Too much existing code to refactor
2. Backward compatibility trap - Must support ancient input files
3. Feature-driven development - Add features by adding types, not abstraction
4. No architectural vision - No incentive to refactor what "works"

ABAQUS is a powerful product with terrible architecture. A warning example for software engineering education.

AbaqusReader's Solution

What We Do

We extract topology separately from physics:

mesh = abaqus_read_mesh("model.inp")

# Returns:
mesh["elements"][1] = [1, 2, 3]              # Connectivity
mesh["element_types"][1] = :Tri3             # Topological type
mesh["element_codes"][1] = :CPS3             # Original ABAQUS name

Users compose their own physics:

# User's FEM code
elem = Tri3(mesh["elements"][1])
code = mesh["element_codes"][1]  # :CPS3 tells us it was plane stress

physics = if code == :CPS3
    PlaneStress()
elseif code == :CPE3
    PlaneStrain()
else
    error("Unknown physics for $code")
end

K = stiffness(elem, physics)  # Clean composition

Why This Is Correct

1. Separation of concerns - Topology independent of physics
2. Linear complexity - 15 topological types vs. ABAQUS's 100+
3. Extensible - Add physics without touching topology code
4. Composable - Users build behavior from orthogonal pieces
5. Modern - Uses Julia's type system properly

What We Preserve

• ✓ Original ABAQUS element names in element_codes (full traceability)
• ✓ Node connectivity and numbering
• ✓ Element sets and surfaces
• ✓ Material names (but not properties - that's physics)

What We Don't Replicate

• ✗ ABAQUS's element type proliferation
• ✗ Coupling topology with physics
• ✗ Exponential complexity
• ✗ Code duplication

We're software engineers. We insulate Julia users from ABAQUS's architectural problems.

For Educators: Using ABAQUS as a Teaching Example

ABAQUS is a perfect case study for teaching software engineering principles because it demonstrates clear violations of established best practices.

What This Demonstrates

1. SOLID Principles - All five violated in one design
2. Separation of Concerns - Orthogonal dimensions mixed together
3. Complexity Analysis - Exponential vs. linear growth patterns
4. Technical Debt - How poor decisions compound over decades
5. Type System Design - Using language features vs. nomenclature hacks
6. Maintainability - Why extensibility matters from day one

Design Review Questions

When reviewing any software design, ask these questions:

1. Single Responsibility

• Does each class/type have exactly one reason to change?
• Are multiple concerns bundled together?
• ABAQUS Example: Element types mix topology + physics + integration

2. Open/Closed

• Can I add features without modifying existing code?
• Will adding dimension X require creating N×M variants?
• ABAQUS Example: New physics → must create N new element types

3. Liskov Substitution

• Are similar types truly interchangeable?
• Can I abstract over categories?
• ABAQUS Example: CPS3 and CPE3 both triangles, but not substitutable

4. Interface Segregation

• Do clients depend on functionality they don't use?
• Are interfaces fat or focused?
• ABAQUS Example: Need topology? Get physics too (unwanted)

5. Dependency Inversion

• Do I depend on abstractions or concrete types?
• Am I coupled to specific implementations?
• ABAQUS Example: Hardcoded element type name strings everywhere

6. Are Concerns Orthogonal?

• Do these dimensions vary independently?
• If YES → Separate types that compose
• If NO → Single abstraction may be OK
• ABAQUS Example: Topology and physics are orthogonal but coupled

7. Am I Creating Exponential Complexity?

• Will adding dimension X require variants of all Y?
• If YES → You're creating exponential explosion
• If NO → Good, concerns are separated
• ABAQUS Example: T × P × I × F = 240+ types

The Lessons

Teaching Exercise

Give students this scenario: "You're designing a FEM library. You need to support:

• 10 element topologies (triangles, quads, tets, hexes, etc.)
• 5 physics formulations (plane stress, plane strain, 3D, axisymmetric, shells)
• 3 integration schemes (full, reduced, selective)
• 2 special features (hybrid, incompatible modes)

Bad approach (ABAQUS style): Create 10 × 5 × 3 × 2 = 300 element type classes

Good approach (modern style): Create 10 + 5 + 3 + 2 = 20 types that compose

Discussion points:

• Which violates SOLID? (Bad approach violates all five)
• Which is easier to extend? (Good approach: add one type, not 60)
• Which has less code duplication? (Good approach: DRY)
• What happens when you add dimension 5? (Bad: 300→1500 types, Good: 20→25 types)

Summary: ABAQUS as a Warning

Bottom Line

ABAQUS demonstrates what NOT to do. Modern languages show how to do it right.

As proud software engineers, we should call out bad design when we see it - even in commercial products. Learn from both.

See Also

• Supported Elements - Complete element type listing
• Examples - Usage examples
• Home - Quick start guide
